Are Betckey Compatible Zebra Labels Compatible with All Models of Zebra Label Printers?

Written by: BernauLena

|

|

Time to read 7 min

Betckey produces cost-effective Zebra-compatible labels, primarily designed for Zebra desktop label printers. These labels are carefully crafted to match the specifications of most Zebra desktop models, ensuring seamless compatibility. However, Zebra offers a diverse range of printers beyond desktop models, including industrial, mobile, and specialized printers. Not all of these may be fully compatible with Betckey labels. Let’s take a closer look at the compatibility across different Zebra printer types.

Key Compatibility Factors Between Zebra Printers and Betckey Compatible Zebra Labels

To ensure compatibility between your Zebra printer and Betckey labels (apply to most other label brands as well), there are five main factors to consider:


1. Printing Technology: Zebra printers use thermal printing technology, which is compatible with Betckey labels.

2. Detection Method: Zebra thermal label printers use gap detection. This definitely applies to Betckey compatible Zebra labels, which are designed to used on Zebra thermal Desktop label printers.

3. Paper Width: Different printers support different label widths.

4. Maximum Label Roll Diameter: Each printer model supports a different maximum label roll diameter. Betckey Zebra labels typically have a diameter between 80-100 mm.

5. Paper Thickness: Each Zebra printer has specific requirements for label thickness. Betckey Zebra labels have a thickness of approximately 0.147 mm.



Zebra Printers

Betckey Compatible Zebra Labels

Printing Technology

ALL models supports direct thermal printers

Supports direct thermal printing across models

Detection Method

Supports gap detection

gap detection

Paper Width

Varies by model

Varies by Label size

Core Diameter

Varies by model

Varies by Label size

Roll Outer Diameter

Varies by model

Varies by Label size

Paper Types

Supports continuous, die-cut, notch, black mark labels

Die-cut

One additional factor that could impact compatibility is the single paper (label) thickness that a printer can support. However, since Betckey and most label manufacturers produce labels within the thickness range of thermal label printers, this is generally not a concern.

By comparing these specifications, we can better understand which Zebra printers are compatible with Betckey Zebra labels and identify any potential limitations.

Compatibility of Betckey Compatible Zebra labels to Zebra Printers

Compatibility with Zebra Desktop Printers

Zebra’s desktop printer lineup includes models of:

ZD600 Series (ZD621-HC, ZD621, ZD621R, ZD611-HC, ZD611R, ZD611)

ZD400 Series (ZD421C, ZD421C-HC, ZD411-HC, ZD411, ZD421, ZD421-HC)

ZD200 Series (ZD220)

along with the ZD510-HC Wristband Printing Solution. Among these, Betckey-compatible Zebra labels are fully compatible with all models(the core diameter for these printers is in inch, and the outer label roll for these printers is 5 inch, a perfect match for  Betckey Zebra labels ), except for the ZD510-HC, provided that the label width falls within the supported range.

The ZD510-HC Wristband Printing Solution is specifically designed for printing wristbands and supports only three printing widths:

  • · 0.75 in. (19.05 mm)
  • · 1 in. (25.4 mm)
  • · 1.1875 in. (30.16 mm)

Additionally, the minimum print length is 3 in. (76 mm), which differs from standard label requirements. Currently, Betckey does not manufacture label rolls compatible with the ZD510-HC model. However, if you require a large bulk order for custom labels suited for this printer, we welcome inquiries for special production requests.

Compatibility with Zebra Mobile and Healthcare Printers

Zebra Mobile Printers

Zebra’s mobile printer lineup includes:

  • · ZQ600 Plus Series Mobile Printers
  • · ZQ300 Plus Series Mobile Printers

Betckey-compatible Zebra labels are not suitable for these models. The main reason is that mobile printers are designed for portability and typically accommodate smaller label rolls. Betckey’s standard label rolls have an outer diameter of around 100mm, which exceeds the size limits of Zebra’s mobile printers.


Healthcare Printers

Similarly, Zebra Healthcare Printers are not compatible with Betckey labels. Like mobile printers, Zebra healthcare printers are compact and cannot accommodate standard Betckey-compatible label rolls with an outer diameter of approximately 100mm.

For users requiring labels for mobile or healthcare printers, custom-sized label rolls may be necessary. If you have bulk order requirements, feel free to contact us for tailored solutions.

Compatibility with Small Office/Home Office Printers and ID Card Printers

Small Office/Home Office (SOHO) Printers

Betckey-compatible Zebra labels are not suitable for Zebra’s SOHO printers because these models work exclusively with Zebra Label Cartridges. Currently, Betckey does not manufacture compatible cartridges for these printers.

The affected models include:

  • · ZSB-DP22 (2-inch printer): Only supports 1-inch and 2-inch label rolls, requires Zebra Label Cartridges.
  • · ZSB-DP24 (4-inch printer): Only supports 1-inch, 2-inch, and 4-inch label rolls, requires Zebra Label Cartridges.

Since these printers use a proprietary cartridge system, standard label rolls like those from Betckey cannot be used.


ID Card Printers

Betckey labels are also not compatible with Zebra ID card printers, as these devices are specifically designed to print plastic ID cards rather than paper labels.

The affected models include:

  • · ZC10L Large-format Card Printer
  • · ZXP Series 7 Card Printers
  • · ZC300 Series Card Printers
  • · ZC100 Card Printer

Since these printers do not support label printing, Betckey-compatible Zebra labels cannot be used with them.

Compatibility with Zebra Industrial Printers

Betckey-compatible Zebra and Dymo labels are not suitable for Zebra Industrial Printers. The primary reason is that industrial printers require label rolls with a 3-inch core diameter, while Betckey’s standard rolls have a 1-inch core diameter. Additionally, some models, such as the 220Xi4, require a minimum paper width of 4.25 inches (108 mm), which does not align with mainstream market demand or Betckey’s standard product lineup.

For businesses in need of a cost-effective custom label solution for industrial printers, we offer bulk order customization. Feel free to contact our customer support team at  cs@betckey.com for more details.

Zebra Industrial Printers and Their Label Compatibility Requirements:

Industrial Printer Model

Label Roll Diameter Requirement

Core Diameter Requirement

Paper Width Range

ZT400 Series

8.0 in. (203 mm) O.D.

3 in. (76 mm) I.D.

1.00 in. (25.4 mm) to 4.5 in. (114 mm) (tear/cutter) / 1.00 in. (25.4 mm) to 4.25 in. (108 mm) (peel/rewind)

ZT400 Series (RFID)

8.0 in. (203 mm) O.D.

3 in. (76 mm) I.D.

Same as ZT411 but with RFID capability

ZT600 Series (ZT610 & ZT610 RFID)

8.0 in. (203 mm) O.D.

3 in. (76 mm) I.D.

0.79 in. (20 mm) to 4.5 in. (114 mm)

ZT620

8.0 in. (203 mm) O.D.

3 in. (76 mm) I.D.

2.0 in. (51 mm) to 7.1 in. (180 mm)

ZT510

8.0 in. (203 mm) O.D.

3 in. (76 mm) I.D.

0.79 in. (20 mm) to 4.5 in. (114 mm)

ZT200 Series (ZT231 & ZT231 RFID)

8.0 in. (203 mm) O.D.

3 in. (76 mm) I.D.

0.75 in. (19.4 mm) to 4.50 in. (114 mm)

ZT100 Series (ZT111)

8.0 in. (203 mm) O.D.

3 in. (76 mm) I.D.

0.75 in. (19.4 mm) to 4.50 in. (114 mm)

220Xi4

8.0 in. (203 mm) O.D.

3 in. (76 mm) I.D.

4.25 in. (108 mm) to 8.8 in. (224 mm)

Since Betckey labels are designed with a 1-inch core diameter and standard roll size of around 100mm outer diameter, they do not fit the industrial printers’ 3-inch core requirement. If your business needs custom label rolls tailored for industrial printers, feel free to reach out for a bulk order consultation.

Compatibility with Print Engines

Betckey-compatible Zebra labels are not suitable for Zebra Print Engines. Similar to industrial printers, print engines require label rolls with a larger core diameter, typically 3 inches, while Betckey’s standard label rolls have a 1-inch core diameter.

What Are Print Engines?

Print engines are high-performance printers designed for high-intensity production environments, surpassing even industrial printers in durability and speed. These printers are commonly used in automated labeling systems for large-scale manufacturing and logistics operations.

Zebra Print Engine Models and Their Requirements:

  • · ZE500 Print Engines Series:
    • o ZE521 RFID, ZE521, ZE511, ZE511 RFID
    • o Require larger core diameters and specific label specifications incompatible with Betckey’s standard label rolls.

Since Betckey labels are designed for desktop and select Zebra-compatible thermal printers, they do not fit the requirements of print engines. If your business requires custom label solutions for print engines, feel free to contact our support team for bulk order inquiries.

Conclusion

Zebra Printer Type

Compatibility with Betckey Zebra and Dymo Labels

Desktop Printers

✅ Compatible (Except ZD510-HC)

Mobile Printers

❌ Not Compatible (Roll diameter too large)

Healthcare Printers

❌ Not Compatible (Size constraints)

Industrial Printers

❌ Not Compatible (Requires a 3-inch core)

Small Office/Home Office Printers

❌ Not Compatible (Requires Zebra label cartridges)

ID Card Printers

❌ Not Compatible (Designed for ID cards)

Print Engines

❌ Not Compatible (Requires a larger core diameter)

If you are using a Zebra desktop printer, you can confidently choose Betckey Zebra and Dymo labels, ensuring cost-effective and high-quality printing. For custom industrial label solutions, please contact Betckey's support team  or call at  +1 323 942 5215 .
