Are Betckey Compatible Zebra Labels Compatible with All Models of Zebra Label Printers?

To ensure compatibility between your Zebra printer and Betckey labels (apply to most other label brands as well), there are five main factors to consider:

1. Printing Technology: Zebra printers use thermal printing technology, which is compatible with Betckey labels.

2. Detection Method: Zebra thermal label printers use gap detection. This definitely applies to Betckey compatible Zebra labels, which are designed to used on Zebra thermal Desktop label printers.

3. Paper Width: Different printers support different label widths.

4. Maximum Label Roll Diameter: Each printer model supports a different maximum label roll diameter. Betckey Zebra labels typically have a diameter between 80-100 mm.

5. Paper Thickness: Each Zebra printer has specific requirements for label thickness. Betckey Zebra labels have a thickness of approximately 0.147 mm.

One additional factor that could impact compatibility is the single paper (label) thickness that a printer can support. However, since Betckey and most label manufacturers produce labels within the thickness range of thermal label printers, this is generally not a concern.

By comparing these specifications, we can better understand which Zebra printers are compatible with Betckey Zebra labels and identify any potential limitations.

Zebra’s desktop printer lineup includes models of:

ZD600 Series (ZD621-HC, ZD621, ZD621R, ZD611-HC, ZD611R, ZD611)

ZD400 Series (ZD421C, ZD421C-HC, ZD411-HC, ZD411, ZD421, ZD421-HC)

ZD200 Series (ZD220)

along with the ZD510-HC Wristband Printing Solution. Among these, Betckey-compatible Zebra labels are fully compatible with all models(the core diameter for these printers is in inch, and the outer label roll for these printers is 5 inch, a perfect match for  Betckey Zebra labels ), except for the ZD510-HC, provided that the label width falls within the supported range.

The ZD510-HC Wristband Printing Solution is specifically designed for printing wristbands and supports only three printing widths:

• · 0.75 in. (19.05 mm)
• · 1 in. (25.4 mm)
• · 1.1875 in. (30.16 mm)

Additionally, the minimum print length is 3 in. (76 mm), which differs from standard label requirements. Currently, Betckey does not manufacture label rolls compatible with the ZD510-HC model. However, if you require a large bulk order for custom labels suited for this printer, we welcome inquiries for special production requests.

Zebra Mobile Printers

Zebra’s mobile printer lineup includes:

• · ZQ600 Plus Series Mobile Printers
• · ZQ300 Plus Series Mobile Printers

Betckey-compatible Zebra labels are not suitable for these models. The main reason is that mobile printers are designed for portability and typically accommodate smaller label rolls. Betckey’s standard label rolls have an outer diameter of around 100mm, which exceeds the size limits of Zebra’s mobile printers.

Healthcare Printers

Similarly, Zebra Healthcare Printers are not compatible with Betckey labels. Like mobile printers, Zebra healthcare printers are compact and cannot accommodate standard Betckey-compatible label rolls with an outer diameter of approximately 100mm.

For users requiring labels for mobile or healthcare printers, custom-sized label rolls may be necessary. If you have bulk order requirements, feel free to contact us for tailored solutions.

Small Office/Home Office (SOHO) Printers

Betckey-compatible Zebra labels are not suitable for Zebra’s SOHO printers because these models work exclusively with Zebra Label Cartridges. Currently, Betckey does not manufacture compatible cartridges for these printers.

The affected models include:

• · ZSB-DP22 (2-inch printer): Only supports 1-inch and 2-inch label rolls, requires Zebra Label Cartridges.
• · ZSB-DP24 (4-inch printer): Only supports 1-inch, 2-inch, and 4-inch label rolls, requires Zebra Label Cartridges.

Since these printers use a proprietary cartridge system, standard label rolls like those from Betckey cannot be used.

ID Card Printers

Betckey labels are also not compatible with Zebra ID card printers, as these devices are specifically designed to print plastic ID cards rather than paper labels.

The affected models include:

• · ZC10L Large-format Card Printer
• · ZXP Series 7 Card Printers
• · ZC300 Series Card Printers
• · ZC100 Card Printer

Since these printers do not support label printing, Betckey-compatible Zebra labels cannot be used with them.

Betckey-compatible Zebra and Dymo labels are not suitable for Zebra Industrial Printers. The primary reason is that industrial printers require label rolls with a 3-inch core diameter, while Betckey’s standard rolls have a 1-inch core diameter. Additionally, some models, such as the 220Xi4, require a minimum paper width of 4.25 inches (108 mm), which does not align with mainstream market demand or Betckey’s standard product lineup.

For businesses in need of a cost-effective custom label solution for industrial printers, we offer bulk order customization. Feel free to contact our customer support team at  cs@betckey.com for more details.

Zebra Industrial Printers and Their Label Compatibility Requirements:

Since Betckey labels are designed with a 1-inch core diameter and standard roll size of around 100mm outer diameter, they do not fit the industrial printers’ 3-inch core requirement. If your business needs custom label rolls tailored for industrial printers, feel free to reach out for a bulk order consultation.

Betckey-compatible Zebra labels are not suitable for Zebra Print Engines. Similar to industrial printers, print engines require label rolls with a larger core diameter, typically 3 inches, while Betckey’s standard label rolls have a 1-inch core diameter.

What Are Print Engines?

Print engines are high-performance printers designed for high-intensity production environments, surpassing even industrial printers in durability and speed. These printers are commonly used in automated labeling systems for large-scale manufacturing and logistics operations.

Zebra Print Engine Models and Their Requirements:

• · ZE500 Print Engines Series:
  • o ZE521 RFID, ZE521, ZE511, ZE511 RFID
  • o Require larger core diameters and specific label specifications incompatible with Betckey’s standard label rolls.

Since Betckey labels are designed for desktop and select Zebra-compatible thermal printers, they do not fit the requirements of print engines. If your business requires custom label solutions for print engines, feel free to contact our support team for bulk order inquiries.

If you are using a Zebra desktop printer, you can confidently choose Betckey Zebra and Dymo labels, ensuring cost-effective and high-quality printing. For custom industrial label solutions, please contact Betckey's support team  or call at  +1 323 942 5215 .
