printers and labels

Are Betckey Zebra and Dymo Labels Compatible with TSC Label Printers?

Written by: BernauLena

|

|

Time to read 4 min

TSC provides professional printing solutions with a diverse product line, covering mobile, desktop, and industrial printers. Below, we will analyze the compatibility of Betckey Zebra and Dymo labels with different categories of TSC printers.

Compatibility of Betckey Zebra and Dymo labels with TSC Label Printers

Mobile Printers

Conclusion: Not Compatible.

Not just TSC, but all mobile label printers have a small maximum label roll outer diameter. For example, the Alpha-40L model supports a maximum roll diameter of 2.64" (67 mm). However, Betckey label rolls typically have a much larger diameter, making them physically incompatible unless custom-sized. Custom orders usually require a minimum order quantity, which is not cost-effective. Therefore, we do not recommend using Betckey Zebra, or Dymo labels with mobile printers.

Desktop Label Printers

All TSC desktop label printers support Direct Thermal technology (some models also support Thermal Transfer technology). Additionally, all models support gap or gap + notch detection methods, making them compatible with Betckey Zebra labels, Dymo U.S. version (gap detection), and Dymo European version (gap + notch detection), provided that the label size falls within the supported paper width range of the printer.

Desktop Printer Compatibility Table

Model

Printing Technology

Detection Method

Paper Width

Paper Type

Max. Paper Roll Outer Diameter

Inner Core

TDP-225

Direct Thermal

Gap, Black Mark

0.59" - 2.36" (15 - 60 mm)

Continuous; Die-Cut; Black Mark; Fan-Fold; Notched; Wristband (Outside Wound)

5" (127 mm)

1" - 1.5" (25.4 - 38 mm)

TDP-225W

Direct Thermal

Gap, Black Mark

0.59" - 2.05" (15 - 52 mm)

Continuous; Die-Cut; Black Mark; Fan-Fold; Notched; Wristband (Outside Wound)

6.5" (165 mm)

1" (25.4 mm)

TH220T

Direct Thermal/Thermal Transfer

Gap, Black Mark

0.59" - 2.36" (15 - 60mm)

Continuous, Die-Cut, Black Mark, Fan-Fold, Notch (Outside Wound)

5" (127mm)

1" - 1.5" (25.4 - 38.1mm)

TH320T

Direct Thermal/Thermal Transfer

Gap, Black Mark

0.59" - 2.36" (15 - 60mm)

Continuous, Die-Cut, Black Mark, Fan-Fold, Notch (Outside Wound)

5" (127mm)

1" - 1.5" (25.4 - 38.1mm)

TH240

Direct Thermal/Thermal Transfer

Gap, Black Mark

0.59" - 4.72" (15 - 120mm)

Continuous, Die-Cut, Black Mark, Fan-Fold, Notch (Outside Wound)

5" (127mm)

1" - 1.5" (25.4 - 38.1mm)

TH340

Direct Thermal/Thermal Transfer

Gap, Black Mark

0.59" - 4.72" (15 - 120mm)

Continuous, Die-Cut, Black Mark, Fan-Fold, Notch (Outside Wound)

5" (127mm)

1" - 1.5" (25.4 - 38.1mm)

Conclusion: Desktop label printers from TSC are compatible with Betckey Zebra and Dymo labels as long as the paper width and roll diameter fit within the printer specifications.

Industrial Printers

Industrial label printers offer greater durability and functionality than desktop models, but their core technology remains the same. Therefore, TSC industrial printers are compatible with Betckey Zebra and Dymo labels, provided that the label size is within the supported paper width range.

TSC Industrial Printer Series:

  • · ML Series – 4-Inch Compact Industrial Printers
  • · MB Series – 4-Inch Performance Industrial Printers
  • · MH Series – 4-Inch Performance Industrial Printers
  • · MX Series – 4-Inch Performance Industrial Printers
  • · MH Series – 6-Inch Performance Industrial Printers
  • · TTP Series – 6-Inch and 8-Inch Performance Industrial Printers

Conclusion: If your label dimensions fall within the supported range, Betckey Zebra and Dymo labels are compatible with TSC industrial printers.

RFID Printers

Conclusion: Not Compatible.

TSC RFID printers are specifically designed to support RFID labels and on-metal tags. Standard Betckey, Zebra, and Dymo labels are not compatible with RFID printers.

Barcode Inspection Printers

Barcode Inspection Printers are capable of printing various types of labels while offering unique verification features. These printers automatically inspect barcode clarity, contrast, spacing, and defects, alerting users to any issues.

Although these printers use Direct Thermal technology, compatibility primarily depends on paper width and core diameter. The minimum core diameter requirement for TSC Barcode Inspection Printers is 1.5 inches, which is larger than the standard Betckey Labels core diameter (1 inch). Therefore, custom labels are required for compatibility.

TSC Barcode Inspection Printer Models:

  • · T6000e Series – 4-Inch Enterprise Industrial ODV-2D Printers
  • · T8000 Series – 4-Inch and 6-Inch Enterprise Industrial ODV-2D Printers

Conclusion: Standard Betckey labels do not fit these printers unless custom-sized.

Conclusion

  • · Bixolon label printers are highly compatible with Betckey, Zebra, and Dymo labels, as long as the label dimensions fit within the printer's specifications.
  • · All Bixolon models support gap detection, making them ideal for Zebra and Dymo U.S. and European label versions.
  • · Industrial and desktop printers offer wide compatibility, but always check paper width and roll diameter before purchasing labels.

By following these guidelines, users can confidently select and use third-party labels with their Bixolon printers without any compatibility concerns.
