Are Betckey Zebra and Dymo Labels Compatible with Bixolon Label Printers?

Written by: BernauLena

|

|

Time to read 5 min

Bixolon is a professional manufacturer specializing in POS systems, mobile printers, and label printers. Their label printers are known for high precision and industrial-grade performance, covering both desktop and industrial models. Given the variety of sensors and detection methods Bixolon printers support, understanding their compatibility with Betckey is essential for users looking to optimize their printing process.

This article will explore whether Betckey Zebra and Dymo labels are compatible with Bixolon label printers, considering key factors such as sensor technology, detection methods, and paper size compatibility.


Bixolon Printer Sensors and Detection Methods

Bixolon label printers employ multiple sensor types to detect labels, ensuring accurate and efficient printing. Below are the main detection methods used in their printers:

1. Sensor Transmissive (Fixed)

  • · This transmissive sensor is used to detect transparent or semi-transparent gaps between labels (Gap Labels).
  • · It is compatible with Dymo’s gap/gap + notch detection and Zebra’s gap detection methods.

2. Reflective (Adjustable) Sensor

  • · This reflective sensor detects black marks on the back of labels, ensuring reliable detection of Black Mark Labels.
  • · It is commonly used to determine whether a label roll has run out.

3. Head Open Sensor

  • · This safety feature detects whether the printhead is properly closed.
  • · If the printhead is open, the printer will not operate to prevent misprints or hardware damage.

Since all Bixolon models support Direct Thermal printing, and some support Thermal Transfer as well, they are designed to work with a variety of labels.

Bixolon printers universally support gap or gap + notch detection methods, meaning that they are compatible with Zebra labels, Dymo labels (both U.S. and European versions), and Betckey labels, as long as the paper size matches the printer’s specifications.

Basic Information of Bixolon Printers

Basic Information of Bixolon Desktop Printers



XD5-40d

XD5-40t

XD5-40tR

XD3-40d

XD3-40t

Printing Technology

Direct Thermal

Thermal Transfer, Direct Thermal

Thermal Transfer or Direct Thermal

Direct Thermal

Thermal Transfer or Direct Thermal

Detection Method

Transmissive (Adjustable), Reflective (Adjustable), Ribbon-End, Head Open

Transmissive (Adjustable), Reflective (Adjustable), Ribbon-End, Head Open

Transmissive (Fixed), Reflective (Adjustable), Ribbon-End, Head Open

Transmissive(Fixed), Reflective(Adjustable), Head Open

Transmissive(Fixed), Reflective(Adjustable), Head Open, Ribbon-End

Paper Width

15 ~ 118 mm

15 ~ 118 mm

15 ~ 118 mm

15 ~ 118 mm

15 ~ 118 mm

Paper Type

Gap, Black Mark, Notch, Continuous, Fan-Fold

Gap, Black Mark, Notch, Continuous, Fan-Fold

Gap, Black Mark, Notch, Continuous, Fan-Fold

Gap, Black Mark, Notch, Continuous, Fan-Fold

Gap, Black Mark, Notch, Continuous, Fan-Fold

Paper Roll Diameter

Up to 127 mm

Up to 127 mm

Up to 127 mm

Up to 127 mm

Up to 127 mm

Inner core

25.4 ~ 38.1mm

25.4 mm, 12.7 mm

25.4 ~ 38.1 mm

25.4 ~ 38.1mm

25.4 ~ 38.1mm

Connection Method

USB, WLAN,Bluetooth, Serial, Ethernet

USB, WLAN,Bluetooth, Serial, Ethernet

USB,WiFi, Ethernet

USB,Serial, Ethernet

USB,Serial, Ethernet

Max. Printing Speed

7 ips (178 mm/sec)

6 ips (152 mm/sec)

6 ips (152 mm/sec)

5 ips (127 mm/sec)

5 ips (127 mm/sec)

Print Resolution

203 dpi

203 dpi

203 dpi

203 dpi

203 dpi




SLP-TX220



SLP-DX220



XQ-840II



SPP-L410



SLP-DL410



XL5-40

Printing Technology

Thermal Transfer, Direct Thermal

Thermal Transfer, Direct Thermal

Direct Thermal

Direct Thermal

Direct Thermal

Direct Thermal

Detection Method

Transmissive, Reflective (Adjustable), Head open

Transmissive, Reflective (Adjustable), Head open

Transmissive, Reflective (Adjustable), Head Open

Paper End Gap Black Mark Paper Cover Open

Transmissive, Reflective (adjustable), Head open

Gap(Fixed) / Black mark(Adjustable), Head Open, Paper Taken Sensor

Paper Width

15 ~ 60 mm

15 ~ 60 mm

15 ~ 118 mm

112 mm / 105 mm (Optional)

25 ~ 116 mm

20 ~ 114mm

Paper Type

Gap, Black Mark, Notch, Continuous, Fan-Fold

Gap, Black Mark, Notch, Continuous, Fan-Fold

Gap, Black Mark, Notch, Continuous, Fan-Fold

Liner, Linerless (Optional)

Gap, Black Mark, Notch, Continuous, Fan-Fold

Linerless: Continuous, Black Mark Linered : Gap, Black Mark, Fan-Fold

Paper Roll Diameter

Up to 130 mm

Up to 130 mm

Up to 130 mm

Up to 56 mm

External roll media options up to Ø 150 mm to 205 mm

Up to 127mm

Inner core

12.5 ~ 38.1mm

12.5 ~ 38.1mm

25.4 to 38.1 mm (With Wall Mount Bracket: 25.4mm)

(19 mm)0.75 Inch

External roll

38.1 mm (1.5 inch) - Recommended 25.4 mm (1 inch)

Connection Method

Standard: USB + Serial Optional: ① USB + Ethernet + WLAN ② USB + WLAN + Bluetooth

Standard: USB + Serial Optional: ① USB + Ethernet + WLAN ② USB + WLAN + Bluetooth

2 USB Host, WLAN, Bluetooth

Standard: USB V2.0 HS + Serial Optional: USB V2.0 HS + Serial + Bluetooth / WLAN

Interface Standard: USB + WLAN Optional: ① USB + Ethernet + WLAN② USB + Ethernet + WLAN+ Bluetooth ③ USB + WLAN + Bluetooth

USB, WLAN,Bluetooth, Serial, Ethernet

Max. Printing Speed

6 ips (152 mm/sec)

6 ips (152 mm/sec)

6 ips (152 mm/sec)

Up to 4 ips (102 mm/sec - Liner) Up to 3 ips (76 mm/sec - Linerless)

5 ips (127 mm/sec)

6 ips (152 mm/sec)

Print Resolution

203 dpi

203 dpi

203 dpi

203 dpi

203 dpi

203 dpi

Basic Information of Bixolon Industrial Printers



XT5-40

XT5-40

XT3-40

Printing Technology

Thermal Transfer, Direct Thermal

Thermal Transfer or Direct Thermal

Thermal Transfer, Direct Thermal

Detection Method

Transmissive (Adjustable), Reflective (Adjustable), Ribbon-End, Head Open

Transmissive (Adjustable), Reflective (Adjustable), Ribbon-End, Head Open

Transmissive (Adjustable), Reflective (Adjustable), Ribbon-End, Head Open

Paper Width

25 ~ 114 mm

25 ~ 114 mm

20 ~ 114mm

Paper Type

Gap, Black Mark, Notch, Continuous, Fan-Fold

Gap, Black Mark, Notch, Continuous, Fan-Fold

Gap, Black Mark, Notch, Continuous, Fan-Fold

Paper Roll Diameter

Up to 203 mm

Up to 203 mm

Up to 203 mm

Inner core

25.4 mm

38.1 ~ 76.2 mm, 25.4 mm (Optional)

25.4 ~ 76.2 mm

Connection Method

USB, WLAN,Bluetooth, Serial, Ethernet

USB, WLAN,Bluetooth, Serial, Ethernet

USB, WLAN,Bluetooth, Serial, Ethernet)

Max. Printing Speed

14 ips (356 mm/sec)

14 ips (356 mm/sec

8 ips (203 mm/sec)

Print Resolution

203, 300, optional

203, 300,optional

203 dpi

Conclusion

  • · Bixolon label printers are highly compatible with Betckey, Zebra, and Dymo labels, as long as the label dimensions fit within the printer's specifications.
  • · All Bixolon models support gap detection, making them ideal for Zebra and Dymo U.S. and European label versions.
  • · Industrial and desktop printers offer wide compatibility, but always check paper width and roll diameter before purchasing labels.

By following these guidelines, users can confidently select and use third-party labels with their Bixolon printers without any compatibility concerns.
